USR PMG Diesel Vehicle RV car motohome Generator JEC60 6kVA
Small size, light weight – compact installation
High efficiency – maximum energy
Variable speed – load dependent
230 V AC output – reliable power supply
Pure sine wave ideal for sensitive electronics
High starting capability of air conditioner/compressor
Easy to install – no forced air circulation in the machine room
Environmental protection – low fuel consumption
Quiet operation
Less space required for installation
Can be installed anywhere on the vehicle
The generator can be installed at the center of gravity
Sealed enclosure
All connections are on the housing
USR PMG Diesel Vehicle RV car motohome Generator JEC60 6kVA
All-in-one vehicle-mounted generator:
Frequency conversion technology, variable speed constant voltage and constant frequency, pure sine wave power supply,
The world’s first. Variable speed constant voltage and constant frequency make the noise lower, more fuel-efficient, and the generator life longer.
Stainless steel solid shell, reliable performance has become the leader in the development of this industry,
providing you with trustworthy performance. The snap-on detachable shell will provide you with more convenient repair and maintenance needs.
A more humane debugging method, which breaks complex debugging into pieces, making debugging more humane and simple.
Our generator has a built-in DSP control chip, which is connected to our original RSV technology, which can control the speed of the stepper motor more accurately and quickly, ensuring the constant voltage and frequency output of the motor, reducing noise and saving fuel. .
Built-in original air boost technology, which increases the power by 15%, the engine has enough power to easily drive the AC generator, keeps the engine cool and reduces noise, and the life of the entire generator and engine is longer.
Panel control and wireless remote control are provided.
The USR generator is compact, quiet and powerful, saving up to 40% weight and space! They are ideal for yacht owners who require low noise and low vibration. The generator is distinguished by its modern, innovative and environmentally friendly inverter technology.
The speed of the diesel engine is automatically adjusted according to the user’s changing power needs, while the output voltage of the inverter always remains constant. Compared with conventional generators with fixed speed, variable speed control significantly reduces exhaust emissions and fuel consumption.
The maximum engine speed is 3000 rpm. A constant output voltage of 230 V / 50 Hz or 120 V / 60 Hz is provided to the electrical loads through the inverter.
Features
- Advanced digital control panel provides extensive performance and diagnostic data
- Less weight, size and noise
- Extremely quiet (52dba@7meter)
- Safety shutdowns for all critical functions
- Self protected against overload
- VCS electronic governor provides excellent voltage stability
- Permanent magnet alternator
- Ignition protected for gas boat applications
- Gear driven raw water pump
- Robust twin cylinder Kubota diesel engine
- Comes standard with an auto-start feature and NMEA2000
- Comes complete with harnesses, remote control panel, sound enclosure and remote fuel lift pump
- 2 Year limited warranty
Specifcations
| Generator set | |
| Generator model | JEC60V PMG |
| Approx. capsule dimensions excl. fittings (L x W x H) [mm] | 840 x 510 x 600 |
| Weight [kg] | 183 |
| Sound level (7m / 3m / 1m) [dB] | 52 / 62 / 67 |
| Cooling system | water cooled |
| Standard capsule | Soundproof stainless steel capsule |
| Performance | |
| Nominal output [kW] | 0-6,0 (6 kVA) |
| Continuous output [kW] | 0-5.6 |
| Output voltage [V] | 230 [Customizable voltage: 120V/60hz, 240V/60Hz] |
| Voltage stability [%] | ± 3 % |
| Frequency stability [%] | 50 Hz ± 0.1 Hz |
| Continuous cunrrents [Amps] | 19.5 |
| Frequency regulation | ECU electronic |
| Control | |
| Starter system | 12V electric starter |
| Autostart | integrated |
| Remote control panel | USR Control digital display |
| Inverter | PMG 6000 |
| Inverter cooling | air-cooled |
| Inverter weight | 10.5 |
| Inverter box dimensions | inside |
| Engine | |
| Engine manufacturer | Kubota |
| Engine type | Z482 |
| Engine displacement [L} | 0.479 |
| Speed [rpm] | 2300-3000 |
| Engine water temperature | 98 |
| EngineHeating | 0-30 |
| Alernator | |
| Model | PMG60 |
| Alternator type | Brushless permanent magnet alternator |
| Rated Power [kVA] | 0-8.5 |
| Altenator cooling | air-cooled |
| Voltage range [V] | 290-415 |
| Temperature rise [℃] | -180 |
Standard Accessories
The standard accessories of this generator are as follows:
| JEC60/80V Packing list | ||||
| No. | Name | Descripition | quantity | Unit |
| 1 | Genset JEC 60/80 | 1 | PCS | |
| 2 | Control penel | 1 | PC | |
| 3 | remote control cable | 5 | Meter | |
| 4 | Engine Maunaul | 1 | PC | |
| 5 | User Manual | 1 | PC | |
| 6 | Engine oil funnel | 1 | PC | |
| 7 | Tubing components | 1.6mm Fuel pipe 3m*1 2.6mm Fuel pipe 1m*1 3.6mm Fuel pipe 2m*1 4.fuel filter 1pc, | 1 | Set |
| 8 | Shock absorber | 100kg | 4 | PCS |
| 9 | Hexagon Screw | M12*30 | 4 | PCS |
| 10 | Steel Gasket | 13*50*3 | 4 | PCS |
| 11 | Current protection switch | 50A | 1 | PC |
| 12 | External suppressor | 1.8L | 1 | PC |
| 13 | Metal Hose | 1.2*1M | 1 | PC |
Downloads
USR PMG Diesel Vehicle RV car motohome Generator JEC60 6kVA
Download this series Brochure
Vehicle generator set JEC60V JEC80V brochure
